LAB1/0-38-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (1/0)AWG 135.38mm 22.35mm Tin
PDF
/
Buying Options
Total Price: USD $32.13
Unit Price: USD $32.126663
≥1 USD $32.126663
≥200 USD $12.819156
≥500 USD $12.39115
≥1000 USD $12.179773
Inventory: 2908
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Aluminum
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Body Material Aluminium
Technical
Packaging Bulk
Published 2001
Series LAB
Feature Gel Filled
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 22.35mm
Contact Finish Tin
Wire Gauge 1/0 AWG
Terminal and Terminal Block Type RING TERMINAL
Safety Approval CSA; UL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Wire Cross Section 53.51 mm2
Stud/Tab Size 3/8 Stud
Terminal Style Two Stud Holes
Dimensions
Length 135.382mm
Length - Overall 5.330 135.38mm
Width - Outer Edges 0.880 22.35mm
Tab Thickness 0.250 6.35mm
Diameter - Barrel ID 0.394 (10.01mm)
Diameter - Barrel OD 0.640 (16.26mm)
Diameter - Ring ID 0.430 (10.92mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
