LAA2-56-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 2AWG 66.8mm 19.05mm Tin
PDF
/
Inventory: 5920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Feature Gel Filled
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 19.05mm
Contact Finish Tin
Wire Gauge 2 AWG
Wire/Cable Gauge 2 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Rectangular Tongue
Stud/Tab Size 3/16 Stud
Terminal Style Single Stud Hole
Terminal Gender FEMALE
Published 2011
Packaging Bulk
Dimensions
Length 66.802mm
Length - Overall 2.630 66.80mm
Width - Outer Edges 0.750 19.05mm
Tab Thickness 0.170 4.32mm
Diameter - Barrel ID 0.310 (7.87mm)
Diameter - Barrel OD 0.530 (13.46mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Body Material Aluminium
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Aluminum
Supply Chain
Factory Lead Time 4 Weeks
