H2L13-2N-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT LUG 2/0-1AWG #1/2
PDF
/
Buying Options
Total Price: USD $87.85
Unit Price: USD $87.8504
≥1 USD $87.8504
Inventory: 38
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Tab Thickness 0.220 5.59mm
Width - Outer Edges 1.630 41.40mm
Length - Overall 4.000 101.60mm
Length 101.6mm
Technical
Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 1 AWG
Wire Gauge (Min) 0 AWG
Wire Gauge (Max) 1 AWG
Wire Gauge 2/0-1 AWG
Depth 41.4mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature 2 Cable Entries, With Screw
Series H2L-2N
Published 2004
Packaging Bulk
Physical
Body Material Copper
Weight 997.903214g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 4 Weeks
