CXS35-36T-C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT LUG 6-14AWG #3/16
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2014
Series Pan-Lug?
Feature With Screw
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
Contact Finish Tin
Wire Gauge 6-14 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 6 AWG
Insulation Non-Insulated
Terminal Type Lug, Grounding
Stud/Tab Size 3/16 Stud
Terminal Style Single Stud Hole
Dimensions
Length 27.432mm
Length - Overall 1.080 27.43mm
Width - Outer Edges 0.380 9.65mm
Tab Thickness 0.050 1.27mm
Compliance
RoHS Status ROHS3 Compliant
