CX35-36-DY
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 6-14AWG 25.9mm 9.65mm
PDF
/
Inventory: 4191
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Body Material Copper
Technical
Packaging Bulk
Published 2013
Series CX
Feature With Screw
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 9.65mm
Wire Gauge 6-14 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 6 AWG
Terminal and Terminal Block Type RING TERMINAL
Safety Approval CSA; UL
Insulation Non-Insulated
Terminal Type Lug, Grounding
Stud/Tab Size 3/16 Stud
Terminal Style Single Stud Hole
Dimensions
Length 25.9mm
Width - Outer Edges 0.380 9.65mm
Tab Thickness 0.070 1.78mm
Diameter - Ring ID 0.200 (5.08mm)
Compliance
RoHS Status RoHS Compliant
