CD70-14-QY
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminal Rectangular Connector
PDF
/
Inventory: 3084
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2011
Series CD
Feature With Screw
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
Number of Rows 1
HTS Code 8536.90.40.00
Pitch 25.4mm
Orientation Straight
Wire Gauge 2-8 AWG
Number of Circuits 2
Max Current Rating 90A
Wire Gauge (Max) 8 AWG
Wire Gauge (Min) 2 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Lug, Grounding
Stud/Tab Size 1/4 Stud
Terminal Style Two Stud Holes
Terminal Gender FEMALE
Dimensions
Length 57.404mm
Length - Overall 2.260 57.40mm
Width - Outer Edges 0.500 12.70mm
Tab Thickness 0.080 2.03mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
