CD225-56HK-QY
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminal Rectangular Connector
PDF
/
Inventory: 8753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Tab Thickness 0.120 3.05mm
Width - Outer Edges 0.990 25.15mm
Length - Overall 3.386 86.00mm
Length 86.0044mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size 5/16 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Wire Gauge (Min) 0 AWG
Wire Gauge (Max) 2 AWG
Connector Support Type CONNECTOR ACCESSORY
Wire Gauge 4/0-2 AWG
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature With Screw
Series CD
Published 2013
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
