CD225-56-QY

Panduit Corp
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminal Rectangular Connector
PDF
/
Inventory: 3648
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Tab Thickness 0.120 3.05mm
Width - Outer Edges 0.990 25.15mm
Length - Overall 3.386 86.00mm
Length 86.0044mm

Technical

Terminal Gender FEMALE
Terminal Style Two Stud Holes
Stud/Tab Size 5/16 Stud
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 0 AWG
Wire Gauge (Max) 2 AWG
Max Current Rating 225A
Number of Circuits 2
Wire Gauge 4/0-2 AWG
Reach Compliance Code unknown
Orientation Straight
Pitch 25.4mm
HTS Code 8536.90.40.00
Number of Rows 1
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature With Screw
Series CD
Published 2011
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 2 Weeks
