CB650-12-3Y
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT LUG 600-1000MCM
PDF
/
Inventory: 8842
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2011
Series CB
Feature With Screw
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 50.8mm
Wire Gauge 600-1000MCM (kcmil)
Wire Gauge (Max) 1000 AWG
Wire Gauge (Min) 600 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Lug, Grounding
Wire Cross Section 645.16 mm2
Stud/Tab Size 1/2 Stud
Terminal Style Single Stud Hole
Dimensions
Length 117.6mm
Width - Outer Edges 2.000 50.80mm
Tab Thickness 0.250 6.35mm
Diameter - Ring ID 0.591 (15.00mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
