CB35-36-CY
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT LUG 6-14AWG #3/16
PDF
/
Inventory: 3401
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material Copper
Weight 1.084086kg
Technical
Packaging Bulk
Published 2008
Series CB
Feature With Screw
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
Type Mechanical
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 9.7mm
Wire Gauge 6-14 AWG
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 6 AWG
Wire/Cable Gauge 6 AWG
Insulation Non-Insulated
Terminal Type Lug, Grounding
Stud/Tab Size 3/16 Stud
Terminal Style Single Stud Hole
Dimensions
Length 30.226mm
Length - Overall 1.190 30.23mm
Width - Outer Edges 0.380 9.65mm
Tab Thickness 0.070 1.78mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
