30022

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminal Rectangular Connector
PDF
/
Inventory: 3646
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 2012
Series Scotchlok? 30000
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp, Barrel
Color Brown
Contact Finish Electro-Tin
Wire Gauge 2 AWG
Wire/Cable Gauge 2 AWG
Insulation Non-Insulated
Terminal Type Standard
Stud/Tab Size 1/4 Stud
Terminal Style Single Stud Hole

Dimensions

Length 50.038mm
Length - Overall 1.970 50.04mm
Width - Outer Edges 0.626 15.90mm
Diameter - Barrel ID 0.307 (7.80mm)
Diameter - Barrel OD 0.416 (10.57mm)

Compliance

RoHS Status RoHS Compliant
