RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Quick Connects, Quick Disconnect Connectors
Description
CONN QC RCPT 18-22AWG 0.110
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.06688
≥100 USD $0.061952
≥500 USD $0.05896
≥1000 USD $0.055704
≥3000 USD $0.05185
Inventory: 130049
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Material Brass
Contact Plating Unplated
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Tape & Reel (TR)
Published 1997
Series Faston
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Gender Female
HTS Code 8536.90.40.00
Orientation Straight
Depth 3.81mm
Wire Gauge 18-22 AWG
ELV Compliant
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Wire/Cable Gauge 22 AWG
Sealable No
Terminal and Terminal Block Type PUSH-ON TERMINAL
Insulation Diameter 0.060 ~ 0.100 (1.52mm ~ 2.54mm)
Insulation Non-Insulated
Terminal Type Standard
Mating Tab Width 2.794mm
Length - Tab 0.250 6.35mm
Dimensions
Length 16.13mm
Length - Overall 0.635 16.13mm
Tab Thickness 0.020 0.51mm
Width - Tab 0.110 2.79mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Not Applicable
Alternative Model
