8-696362-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Quick Connects, Quick Disconnect Connectors
Description
Quick Connect Terminal
PDF
/
Inventory: 3233
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Tin
Mount Free Hanging
Insulation Material Nylon
Technical
Packaging Bulk
Termination Tab
ECCN Code EAR99
Color Red
Gender Male
HTS Code 8536.90.40.00
ELV Compliant
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 22 AWG
Insulation Diameter 2.921 mm
Insulation Insulated
Wire Cross Section 1.23 mm2
Dimensions
Length 23.1394mm
Tab Thickness 812.8μm
Width - Tab 6.35mm
Compliance
RoHS Status RoHS Compliant
Lead Free Not Applicable
