0357253700
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Quick Connects, Quick Disconnect Connectors
Description
Terminals .250 SLIP ON REC. Q. EC. Q.CONN 357253700
PDF
/
Inventory: 5769
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Brass
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Reel
Series 35725
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Gender Female
HTS Code 8536.90.40.00
Wire Gauge 14-18 AWG
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 14 AWG
Terminal and Terminal Block Type TAB TERMINAL
Insulation Diameter 0.126 (3.20mm)
Insulation Non-Insulated
Terminal Type Standard
Length - Tab 0.307 7.80mm
Dimensions
Length 19.6088mm
Length - Overall 0.772 19.61mm
Tab Thickness 0.032 0.81mm
Width - Tab 0.250 6.35mm
Compliance
RoHS Status ROHS3 Compliant
