0190020004
RoHS
RoHS compliant
RoHS compliantPackage Metal
Category Connectors, Interconnects / Terminals - Quick Connects, Quick Disconnect Connectors
Description
CONN QC RCPT 18-22AWG 0.250
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.36784
≥100 USD $0.285736
≥500 USD $0.224523
Inventory: 58598
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Free Hanging (In-Line)
Package / Case Metal
Insulation Material Nylon
Terminal Material Brass
Technical
Packaging Tape & Reel (TR)
Series Avikrimp
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Color Red
Gender Female
Voltage - Rated 300V
HTS Code 8536.90.40.00
Voltage - Rated DC 300V
Orientation Straight
Contact Finish Tin
Wire Gauge 18-22 AWG
ELV Compliant
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 22 AWG
Wire/Cable Gauge 22 AWG
Terminal and Terminal Block Type PUSH-ON TERMINAL
Halogen Free Low Halogen
Insulation Diameter 0.120 (3.05mm)
Insulation Fully Insulated
Terminal Type Standard
Wire Cross Section 0.8 mm2
Dimensions
Length - Overall 0.890 22.61mm
Tab Thickness 0.032 0.81mm
Width - Tab 0.250 6.35mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-2
Alternative Model
