1257
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Quick Connects, Quick Disconnect Connectors
Description
ROHS3Compliant Right Angle Lead Free Non-Insulated Quick Connect Connector 145C 15A 500V 3.302mm
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.338272
≥100 USD $0.27632
≥500 USD $0.248125
≥1000 USD $0.236861
≥3000 USD $0.197384
Inventory: 10185
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Material Thickness 812.8μm
Width - Tab 0.250 6.35mm
Tab Thickness 0.032 0.81mm
Length 38.1mm
Diameter 3.302mm
Technical
Terminal Type Angled - 90°
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Voltage - Rated AC 500V
Current Rating 15A
Orientation Right Angle
Voltage - Rated DC 500V
HTS Code 8536.90.40.00
Gender Male
Min Operating Temperature -50°C
Max Operating Temperature 145°C
ECCN Code EAR99
Termination Screw, Rivet, Stud
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature 2 Tabs
Packaging Bulk
Physical
Insulation Material Thermoplastic
Mounting Type Board, Chassis
Mount Chassis, Rivet
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
