1428-2 image
Favorite
1428-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description ROHS3Compliant 2005 Lead Free Non-Insulated PC Pin Terminal Connector 0.062 1.57mm
PDF
/
Buying Options
Total Price: USD $5.77
Unit Price: USD $5.7728
≥1 USD $5.7728
≥10 USD $5.48768
Inventory: 104
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Mounting Hole Diameter 0.062 (1.57mm)

Technical

Packaging Bulk
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
Connector Type INTERCONNECTION DEVICE
Contact Finish Tin
Insulation Non-Insulated
Terminal Type PC Pin
Hole Diameter 1.5748 mm
Flange Diameter 0.078 (1.98mm)
Terminal Style Single End
Pin Size - Above Flange 0.025 0.64mm Dia

Dimensions

Length 6.35mm
Contact Finish Thickness 200.0μin 5.08μm
Length - Overall 0.250 6.35mm
Board Thickness 0.062 1.57mm
Length - Below Flange 0.094 2.39mm
Length - Above Flange 0.126 3.20mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
