1428-1
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Test Plugs & Test Jacks .025 PC PIN SWAGE
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.201681
≥1 USD $0.201681
≥10 USD $0.190269
≥100 USD $0.179497
≥500 USD $0.169332
≥1000 USD $0.159752
Inventory: 6046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Package / Case 062
Mounting Hole Diameter 0.062 (1.57mm)
Technical
Packaging Bulk
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
Connector Type INTERCONNECTION DEVICE
Contact Finish Tin
Insulation Non-Insulated
Terminal Type PC Pin
Hole Diameter 1.5748 mm
Flange Diameter 0.078 (1.98mm)
Terminal Style Single End
Pin Size - Above Flange 0.025 0.64mm Dia
Dimensions
Length 5.5372mm
Contact Finish Thickness 200.0μin 5.08μm
Length - Overall 0.218 5.54mm
Board Thickness 0.032 0.81mm
Length - Below Flange 0.062 1.57mm
Length - Above Flange 0.126 3.20mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
