1427-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Single Post Connector
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.176965
≥1 USD $0.176965
≥10 USD $0.166945
≥100 USD $0.157502
≥500 USD $0.148584
≥1000 USD $0.14017
Inventory: 1161
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length - Above Flange 0.179 4.55mm
Length - Below Flange 0.113 2.87mm
Board Thickness 0.093 2.36mm
Diameter - Inside 640 μm
Length - Overall 0.313 7.95mm
Contact Finish Thickness 200.0μin 5.08μm
Length 7.9502mm
Technical
Pin Size - Above Flange 0.025 0.64mm Dia
Terminal Style Single End
Outside Diameter 1.57 mm
Flange Diameter 0.062 (1.57mm)
Hole Diameter 1.3208 mm
Terminal Type PC Pin
Insulation Non-Insulated
Contact Finish Tin
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2000
Packaging Bulk
Physical
Mounting Hole Diameter 0.052 (1.32mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
