1425-2 image
Favorite
1425-2 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description PIN .040" .082"L SWAGE MOUNT SN
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.46547
≥1 USD $0.46547
≥10 USD $0.439119
≥100 USD $0.414264
≥500 USD $0.390815
≥1000 USD $0.3687
Inventory: 1509
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Material Brass
Mounting Hole Diameter 0.043 (1.09mm)

Technical

Packaging Bulk
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
Gender Male
Contact Finish Tin
Plating Tin
Insulation Non-Insulated
Terminal Type PC Pin
Hole Diameter 1.0922 mm
Flange Diameter 0.070 (1.77mm)
Outside Diameter 1.78 mm
Terminal Style Single End
Pin Size - Above Flange 0.040 1.02mm Dia

Dimensions

Diameter 1.0922mm
Height 8.13mm
Length 10.2108mm
Contact Finish Thickness 200.0μin 5.08μm
Length - Overall 0.402 10.20mm
Diameter - Inside 1.02 mm
Board Thickness 0.062 1.57mm
Length - Below Flange 0.082 2.08mm
Length - Above Flange 0.300 7.62mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
