1424-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
ROHS3Compliant 2005 Lead Free Non-Insulated PC Pin Terminal Connector 0.062 1.57mm
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.172308
≥1 USD $0.172308
≥10 USD $0.162554
≥100 USD $0.153346
≥500 USD $0.144677
≥1000 USD $0.136486
Inventory: 2516
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Mounting Hole Diameter 0.052 (1.32mm)
Technical
Packaging Bulk
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
Connector Type INTERCONNECTION DEVICE
Contact Finish Tin
Insulation Non-Insulated
Terminal Type PC Pin
Hole Diameter 1.3208 mm
Flange Diameter 0.062 (1.57mm)
Outside Diameter 1.57 mm
Terminal Style Single End
Pin Size - Above Flange 0.025 0.64mm Dia
Dimensions
Length 4.6228mm
Contact Finish Thickness 200.0μin 5.08μm
Length - Overall 0.182 4.62mm
Diameter - Inside 640 μm
Board Thickness 0.062 1.57mm
Length - Below Flange 0.082 2.08mm
Length - Above Flange 0.079 2.01mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
