1406-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
CONN PC PIN CIRC 0.024DIA GOLD
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26824
≥1 USD $0.26824
≥10 USD $0.253058
≥100 USD $0.238734
≥500 USD $0.225217
≥1000 USD $0.212468
Inventory: 6835
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length - Above Flange 0.188 4.78mm
Length - Below Flange 0.110 2.79mm
Board Thickness 0.093 2.36mm
Length - Overall 0.323 8.20mm
Contact Finish Thickness 10.0μin 0.25μm
Length 8.2042mm
Technical
Pin Size - Above Flange 0.024 0.61mm Dia
Terminal Style Single End
Flange Diameter 0.060 (1.52mm)
Hole Diameter 889 μm
Terminal Type PC Pin
Insulation Non-Insulated
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2000
Packaging Bulk
Physical
Mounting Hole Diameter 0.035 (0.89mm)
Material Gold
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
