1375-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Circuit Board Hardware - PCB PIN
PDF
/
Inventory: 9416
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Above Flange 0.230 5.84mm
Length - Below Flange 0.113 2.87mm
Board Thickness 0.093 2.36mm
Length - Overall 0.363 9.22mm
Contact Finish Thickness 200.0μin 5.08μm
Length 9.2202mm
Technical
Pin Size - Above Flange 0.030 0.76mm Dia
Terminal Style Single End
Flange Diameter 0.094 (2.39mm)
Hole Diameter 1.7018 mm
Terminal Type PC Pin
Insulation Non-Insulated
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Bulk
Physical
Mounting Hole Diameter 0.067 (1.70mm)
Material Tin
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
