RoHS
RoHS RoHS compliant
Package 052
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description Circuit Board Hardware - PCB 1371-2
PDF
/
Inventory: 7713
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length - Above Flange 0.375 9.53mm
Length - Below Flange 0.094 2.39mm
Board Thickness 0.062 1.57mm
Diameter - Inside 640 μm
Length - Overall 0.531 13.50mm
Contact Finish Thickness 10.0μin 0.25μm
Length 13.4874mm
Diameter 1.3208mm

Technical

Pin Size - Above Flange 0.025 0.64mm Dia
Terminal Style Single End
Outside Diameter 1.57 mm
Flange Diameter 0.062 (1.57mm)
Hole Diameter 1.3208 mm
Terminal Type PC Pin
Insulation Non-Insulated
Contact Finish Gold
Gender Male
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2008
Packaging Bulk

Physical

Mounting Hole Diameter 0.052 (1.32mm)
Material Brass, Gold
Package / Case 052
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
