1359-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Test Plugs & Test Jacks .082 MICRO PIN SWAGE MOUNT
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.220373
≥1 USD $0.220373
≥10 USD $0.2079
≥100 USD $0.196127
≥500 USD $0.185026
≥1000 USD $0.174557
Inventory: 4318
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Above Flange 0.380 9.65mm
Length - Below Flange 0.082 2.08mm
Board Thickness 0.062 1.57mm
Length - Overall 0.482 12.24mm
Contact Finish Thickness 200.0μin 5.08μm
Length 12.2428mm
Technical
Pin Size - Above Flange 0.040 1.02mm Dia
Terminal Style Single End
Flange Diameter 0.070 (1.77mm)
Hole Diameter 1.0922 mm
Terminal Type PC Pin
Insulation Non-Insulated
Contact Finish Tin
Connector Type INTERCONNECTION DEVICE
ECCN Code EAR99
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2013
Packaging Bulk
Physical
Mounting Hole Diameter 0.043 (1.09mm)
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
