1357-1 image
Favorite
1357-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description CONN PC PIN CIRC 0.040DIA TIN
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.35122
≥1 USD $0.35122
≥10 USD $0.331342
≥100 USD $0.312583
≥500 USD $0.294891
≥1000 USD $0.278193
Inventory: 6681
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length - Above Flange 0.150 3.81mm
Length - Below Flange 0.176 4.47mm
Board Thickness 0.032 0.81mm
Length - Overall 0.348 8.84mm
Contact Finish Thickness 200.0μin 5.08μm
Length 8.8392mm

Technical

Pin Size - Above Flange 0.040 1.02mm Dia
Terminal Style Single End
Flange Diameter 0.094 (2.39mm)
Hole Diameter 1.9304 mm
Terminal Type PC Pin
Insulation Non-Insulated
Connector Type INTERCONNECTION DEVICE
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2007
Packaging Bulk

Physical

Mounting Hole Diameter 0.076 (1.93mm)
Material Tin
Mounting Type Through Hole
Mount Through Hole
Contact Material Brass

Supply Chain

Factory Lead Time 6 Weeks
