11075
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Circuit Board Hardware - PCB .100 x .210 PTFE Pin Mtg Hole .136"
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.259071
≥1 USD $1.259071
≥200 USD $0.487086
≥500 USD $0.470018
≥1000 USD $0.462141
Inventory: 8170
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Solder, Through Hole
Mounting Type Through Hole, Bottom Entry
Package / Case 100
Material Brass
Material - Insulation Polytetrafluoroethylene (PTFE)
Mounting Hole Diameter 0.136 (3.45mm)
Technical
Packaging Bulk
Published 2007
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Insulation Color White
Contact Finish Tin
Plating Tin
Insulation Insulated
Terminal Type PC Pin
Hole Diameter 3.4544 mm
Flange Diameter 0.172 (4.37mm)
Outside Diameter 4.3688 mm
Terminal Style Single End
Pin Size - Above Flange 0.040 1.02mm Dia
Dimensions
Length 8.89mm
Length - Overall 0.350 8.89mm
Board Thickness 0.062 1.57mm
Length - Above Flange 0.310 7.87mm
Compliance
RoHS Status ROHS3 Compliant
