RoHS
RoHS RoHS compliant
Package 100
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description Circuit Board Hardware - PCB .100 x .490 PTFE pin
PDF
/
Buying Options
Total Price: USD $17.56
Unit Price: USD $17.5648
≥1 USD $17.5648
≥10 USD $16.58976
≥100 USD $15.61472
≥500 USD $15.126496
Inventory: 107
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Contact Material Brass
Contact Plating Tin
Mount Solder, Through Hole
Mounting Type Through Hole
Package / Case 100
Material Brass
Material - Insulation Polytetrafluoroethylene (PTFE)
Mounting Hole Diameter 0.136 (3.45mm)

Technical

Packaging Bulk
Published 2007
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
Insulation Color White
Contact Finish Tin
Plating Tin
Insulation Insulated
Terminal Type PC Pin
Hole Diameter 3.4544 mm
Flange Diameter 0.172 (4.37mm)
Outside Diameter 4.3688 mm
Terminal Style Single End
Pin Size - Above Flange 0.040 1.02mm Dia

Dimensions

Length 14.986mm
Length - Overall 0.590 14.99mm
Board Thickness 0.062 1.57mm
Length - Below Flange 0.100 2.54mm
Length - Above Flange 0.450 11.43mm

Compliance

RoHS Status ROHS3 Compliant
