11068
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Circuit Board Hardware - PCB .075 x .185" PTFE pin
PDF
/
Inventory: 6939
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Above Flange 0.145 3.68mm
Length - Below Flange 0.075 1.91mm
Board Thickness 0.062 1.57mm
Length - Overall 0.260 6.60mm
Length 6.604mm
Technical
Pin Size - Above Flange 0.040 1.02mm Dia
Terminal Style Single End
Outside Diameter 4.3688 mm
Flange Diameter 0.172 (4.37mm)
Hole Diameter 3.4544 mm
Terminal Type PC Pin
Insulation Insulated
Plating Tin
Contact Finish Tin
Insulation Color White
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2007
Packaging Bulk
Physical
Mounting Hole Diameter 0.136 (3.45mm)
Material - Insulation Polytetrafluoroethylene (PTFE)
Material Brass
Mounting Type Through Hole
Mount Solder, Through Hole
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 6 Weeks
