H2174-05
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description
Circuit Board Hardware - PCB 1mm TERMINAL PIN
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.3696
≥1 USD $0.3696
≥10 USD $0.3168
≥100 USD $0.278784
≥500 USD $0.25608
≥1000 USD $0.246048
≥3000 USD $0.22095
Inventory: 9817
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Finish Thickness 0.0039
Length - Above Flange 0.150 3.81mm
Length - Below Flange 0.082 2.08mm
Board Thickness 0.063 1.60mm
Length - Overall 0.252 6.40mm
Length 6.4008mm
Technical
Pin Size - Above Flange 0.041 1.04mm Dia
Terminal Style Single End
Assembly Item Name CONTACT
Flange Diameter 0.070 (1.77mm)
Hole Diameter 1.143 mm
Terminal Type PC Pin
Insulation Non-Insulated
Connector Support Type TERMINAL ACCESSORY
Contact Style ROUND PIN-SOCKET
Depth 1.78mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2001
Packaging Bulk
Physical
Mounting Hole Diameter 0.041 ~ 0.045 (1.04mm ~ 1.14mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Brass
