H2171-05

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description Circuit Board Hardware - PCB TERMINAL LUG
PDF
/
Inventory: 1311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Contact Material Brass
Mount Through Hole
Mounting Type Through Hole
Mounting Hole Diameter 0.041 ~ 0.045 (1.04mm ~ 1.14mm)

Technical

Packaging Bulk
Published 2001
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
ECCN Code EAR99
Connector Type Connector, PCB, Signal
Gender Male
HTS Code 8536.90.40.00
Contact Finish Gold
Terminal and Terminal Block Type PCB TERMINAL
Insulation Non-Insulated
Terminal Type PC Pin
Hole Diameter 1.143 mm
Flange Diameter 0.070 (1.77mm)
Terminal Style Single End
Pin Size - Above Flange 0.041 1.04mm Dia

Dimensions

Length 21.6408mm
Length - Overall 0.852 21.64mm
Board Thickness 0.063 1.60mm
Length - Below Flange 0.082 2.08mm
Length - Above Flange 0.750 19.05mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
