H2170-05

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin, Single Post Connectors
Description Circuit Board Hardware - PCB 1mm TERMINAL PIN
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.3476
≥100 USD $0.317152
≥500 USD $0.298672
≥1000 USD $0.286176
≥3000 USD $0.261325
Inventory: 1614
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Length - Above Flange 0.500 12.70mm
Length - Below Flange 0.082 2.08mm
Board Thickness 0.063 1.60mm
Length - Overall 0.602 15.29mm
Length - Tail 12.7mm
Length 15.2908mm

Technical

Pin Size - Above Flange 0.041 1.04mm Dia
Terminal Style Single End
Outside Diameter 1.91 mm
Flange Diameter 0.070 (1.77mm)
Hole Diameter 1.143 mm
Terminal Type PC Pin
Insulation Non-Insulated
Terminal and Terminal Block Type PCB TERMINAL
Depth 1.78mm
HTS Code 8536.69.40.40
Gender Female
ECCN Code EAR99
Termination Swage
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2001
Packaging Bulk

Physical

Mounting Hole Diameter 0.041 ~ 0.045 (1.04mm ~ 1.14mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Brass

Supply Chain

Factory Lead Time 9 Weeks
