714-87-150-41-014101

Preci-Dip
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description 714 ROHS3Compliant 2012 Gold Pin Receptacle Connector -55C~125C 0.039-0.197 1.00mm-5.00mm
PDF
/
Inventory: 4898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Contact Material Beryllium Copper
Mounting Hole Diameter 0.055 ~ 0.071 (1.40mm ~ 1.80mm)

Technical

Operating Temperature -55°C~125°C
Packaging Strip
Published 2012
Series 714
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Contact Finish Gold
Hole Diameter 1.8034 mm
Flange Diameter 0.072 (1.83mm)
Tail Type No Tail
Accepts Pin Diameter 0.016 ~ 0.022 (0.41mm ~ 0.56mm)
Socket Depth 0.246 6.25mm
Insertion Force 2.00N

Dimensions

Length 7.239mm
Contact Finish Thickness Flash
Length - Overall 0.285 7.24mm
Board Thickness 0.039 ~ 0.197 1.00mm ~ 5.00mm

Compliance

RoHS Status ROHS3 Compliant
