714-87-135-31-018101

Preci-Dip
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description 714 ROHS3Compliant 2012 GENERAL PURPOSE Pin Receptacle Connector -55C~125C 0.039-0.134 1.00mm-3.40mm
PDF
/
Inventory: 6615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Contact Material Beryllium Copper
Mounting Type BOARD
Mounting Style STRAIGHT
Mounting Hole Diameter 0.039 ~ 0.051 (0.99mm ~ 1.30mm)

Technical

Operating Temperature -55°C~125°C
Packaging Strip
Published 2012
Series 714
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD CONNECTOR
Number of Rows 1
Additional Feature LOW PROFILE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 35
Terminal Pitch 2.54mm
Contact Finish Gold
Contact Gender FEMALE
UL Flammability Code 94V-0
Body/Shell Style SOCKET
Hole Diameter 1.2954 mm
Flange Diameter 0.055 (1.40mm)
Tail Type No Tail
Accepts Pin Diameter 0.016 ~ 0.021 (0.41mm ~ 0.53mm)
Socket Depth 0.148 3.76mm
Insertion Force 1.00N

Dimensions

Length 4.2672mm
Contact Finish Thickness Flash
Length - Overall 0.168 4.27mm
Board Thickness 0.039 ~ 0.134 1.00mm ~ 3.40mm

Compliance

RoHS Status ROHS3 Compliant
