714-83-159-41-014101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
714 ROHS3Compliant 2012 GENERAL PURPOSE Pin Receptacle Connector -55C~125C 0.039-0.197 1.00mm-5.00mm
PDF
/
Inventory: 6917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Board Thickness 0.039 ~ 0.197 1.00mm ~ 5.00mm
Length - Overall 0.285 7.24mm
Contact Finish Thickness 30.0μin 0.76μm
Length 7.239mm
Technical
Insertion Force 2.00N
Socket Depth 0.246 6.25mm
Accepts Pin Diameter 0.016 ~ 0.022 (0.41mm ~ 0.56mm)
Tail Type No Tail
Flange Diameter 0.072 (1.83mm)
Hole Diameter 1.8034 mm
Body/Shell Style SOCKET
UL Flammability Code 94V-0
Contact Gender FEMALE
Contact Finish Gold
Terminal Pitch 2.54mm
Total Number of Contacts 59
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Number of Rows 1
Connector Type BOARD CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 714
Published 2012
Packaging Strip
Operating Temperature -55°C~125°C
Physical
Mounting Hole Diameter 0.055 ~ 0.071 (1.40mm ~ 1.80mm)
Mounting Style STRAIGHT
Mounting Type BOARD
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 10 Weeks
