714-83-159-31-008101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
714 ROHS3Compliant 2012 Gold Pin Receptacle Connector -55C~125C 0.060-0.100 1.52mm-2.54mm
PDF
/
Inventory: 5466
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Board Thickness 0.060 ~ 0.100 1.52mm ~ 2.54mm
Length - Overall 0.146 3.71mm
Contact Finish Thickness 30.0μin 0.76μm
Length 3.7084mm
Technical
Insertion Force 1.00N
Socket Depth 0.126 3.20mm
Accepts Pin Diameter 0.016 ~ 0.021 (0.41mm ~ 0.53mm)
Tail Type No Tail
Flange Diameter 0.055 (1.40mm)
Hole Diameter 1.0414 mm
Contact Finish Gold
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 714
Published 2012
Packaging Strip
Operating Temperature -55°C~125°C
Physical
Mounting Hole Diameter 0.041 (1.04mm)
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 10 Weeks
