712-83-164-41-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
712 ROHS3Compliant COMMERCIAL UL Pin Receptacle Connector 500Cycles 10mOhm -55C~125C 3A
PDF
/
Inventory: 2199
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Beryllium Copper
Mounting Type BOARD
Insulation Material GLASS FILLED POLYCYCLOHEXYLENE TEREPHTHALLATE
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Technical
Operating Temperature -55°C~125°C
Packaging Strip
Published 2012
Series 712
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Rows 1
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 64
Terminal Pitch 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 1
Body Breadth 0.072 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Body Depth 0.169 inch
Rated Current (Signal) 3A
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 10000000000Ohm
Mating Contact Pitch 0.1 inch
Body/Shell Style SOCKET
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1400VAC V
Durability 500 Cycles
Contact Pattern RECTANGULAR
Insulator Color BLACK
Flange Diameter 0.072 (1.83mm)
Tail Type Standard Tail
Accepts Pin Diameter 0.016 ~ 0.022 (0.41mm ~ 0.56mm)
Socket Depth 0.146 3.71mm
Tail Diameter 0.020 (0.51mm)
Insertion Force 2.00N
Dimensions
Length 7.366mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Overall 0.290 7.37mm
Compliance
RoHS Status ROHS3 Compliant
