712-83-143-41-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
712 ROHS3Compliant COMMERCIAL UL Pin Receptacle Connector 500Cycles 10mOhm -55C~125C 3A
PDF
/
Inventory: 2002
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Overall 0.290 7.37mm
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Length 7.366mm
Technical
Insertion Force 2.00N
Tail Diameter 0.020 (0.51mm)
Socket Depth 0.146 3.71mm
Accepts Pin Diameter 0.016 ~ 0.022 (0.41mm ~ 0.56mm)
Tail Type Standard Tail
Flange Diameter 0.072 (1.83mm)
Insulator Color BLACK
Contact Pattern RECTANGULAR
Durability 500 Cycles
Dielectric Withstanding Voltage 1400VAC V
Polarization Key POLARIZED HOUSING
Body/Shell Style SOCKET
Mating Contact Pitch 0.1 inch
Insulation Resistance 10000000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.169 inch
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.072 inch
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2.54mm
Total Number of Contacts 43
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 1
Connector Type BOARD CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 712
Published 2012
Packaging Strip
Operating Temperature -55°C~125°C
Physical
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED POLYCYCLOHEXYLENE TEREPHTHALLATE
Mounting Type BOARD
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 10 Weeks
