3591
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
Circuit Board Hardware - PCB JACK (RoHS NON-COMP)
PDF
/
Buying Options
Total Price: USD $18.44
Unit Price: USD $18.436
≥1 USD $18.436
Inventory: 126
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Overall 0.397 10.08mm
Contact Finish Thickness 200.0μin 5.08μm
Length 10.0838mm
Technical
Tail Diameter 0.062 (1.57mm)
Socket Depth 0.180 4.57mm
Accepts Pin Diameter 0.025 ~ 0.037 (0.64mm ~ 0.94mm)
Tail Type Standard Tail
Outside Diameter 1.98 mm
Flange Diameter 0.078 (1.98mm)
Hole Diameter 1.651 mm
Contact Finish Tin
Connector Type INTERCONNECTION DEVICE
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Mounting Hole Diameter 0.065 (1.65mm)
Material Brass
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 6 Weeks
