1679
RoHS
/
Package 317
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
Test Plugs & Test Jacks JACK (RoHS NON-COMP)
PDF
/
Inventory: 5810
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Overall 0.317 8.05mm
Contact Finish Thickness 10.0μin 0.25μm
Length 8.0518mm
Technical
Socket Depth 0.220 5.59mm
Accepts Pin Diameter 0.032 ~ 0.046 (0.81mm ~ 1.17mm)
Tail Type No Tail
Hole Diameter 2.2606 mm
Contact Finish Gold
Connector Type INTERCONNECTION DEVICE
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Physical
Mounting Hole Diameter 0.089 (2.26mm)
Package / Case 317
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 6 Weeks
