1444
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
CONN PIN RCPT .032-.046 SOLDER
PDF
/
Buying Options
Total Price: USD $0.89
Unit Price: USD $0.8888
≥1 USD $0.8888
≥10 USD $0.873664
≥100 USD $0.85536
≥500 USD $0.801011
≥1000 USD $0.710424
≥3000 USD $0.487203
Inventory: 520
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Beryllium Copper
Contact Plating Tin
Mount Solder, Through Hole
Material Brass, Copper
Mounting Hole Diameter 0.076 (1.93mm)
Technical
Packaging Bulk
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Connector, Signal, Socket
Color Gold
Gender Female
Orientation Straight
Shielding Unshielded
Depth 2.28mm
Contact Finish Tin-Lead
Hole Diameter 1.9304 mm
Flange Diameter 0.090 (2.29mm)
Outside Diameter 2.29 mm
Tail Type No Tail
Accepts Pin Diameter 0.032 ~ 0.046 (0.81mm ~ 1.17mm)
Socket Depth 0.221 5.61mm
Dimensions
Height 2.28mm
Length 5.6134mm
Contact Finish Thickness 200.0μin 5.08μm
Length - Overall 0.221 5.61mm
Diameter - Inside 1.83 mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
