1419-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
Terminal Socket Connector
PDF
/
Inventory: 954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Beryllium Copper
Mounting Hole Diameter 0.067 (1.70mm)
Technical
Packaging Bulk
Published 2000
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Swage
ECCN Code EAR99
Connector Type INTERCONNECTION DEVICE
HTS Code 8536.90.40.00
Contact Finish Gold
Hole Diameter 1.7018 mm
Flange Diameter 0.125 (3.18mm)
Tail Type No Tail
Accepts Pin Diameter 0.032 ~ 0.046 (0.81mm ~ 1.17mm)
Socket Depth 0.200 5.08mm
Dimensions
Length 9.8044mm
Contact Finish Thickness 10.0μin 0.25μm
Length - Overall 0.386 9.80mm
Diameter - Inside 1.17 mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
