H3165-46
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
Contact SKT ST
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.334314
≥1 USD $0.334314
≥10 USD $0.315394
≥100 USD $0.297536
≥500 USD $0.280697
≥1000 USD $0.264806
Inventory: 974
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length - Overall 0.222 5.65mm
Contact Finish Thickness 157.5μin 4.00μm
Technical
Insertion Force 3.00N ~ 9.00N
Socket Depth 0.187 4.75mm
Accepts Pin Diameter 0.035 ~ 0.041 (0.89mm ~ 1.05mm)
Tail Type No Tail
Flange Diameter 0.105 (2.67mm)
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Tin
HTS Code 8536.90.40.00
Gender Female
Connector Type Connector, Socket
ECCN Code EAR99
Termination Press-Fit, Knurled
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2015
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Mounting Hole Diameter 0.075 ~ 0.077 (1.91mm ~ 1.96mm)
Mount Socket
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 9 Weeks
