D01-9902005
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
IC & Component Sockets 20PC OF H3153-05 SKT ON CARRIER COMB
PDF
/
Buying Options
Total Price: USD $3.6
Unit Price: USD $3.5992
≥1 USD $3.5992
≥10 USD $3.2692
≥100 USD $3.096342
≥500 USD $3.024305
≥1000 USD $2.880363
≥3000 USD $2.5355
Inventory: 672
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Overall 0.142 3.61mm
Contact Finish Thickness 3.94μin 0.10μm
Length 3.6068mm
Technical
Insertion Force 2.00N ~ 6.00N
Pin Hole Diameter 0.043 (1.09mm)
Socket Depth 0.124 3.15mm
Accepts Pin Diameter 0.016 ~ 0.020 (0.41mm ~ 0.51mm)
Tail Type No Tail
Flange Diameter 0.057 (1.45mm)
Hole Diameter 1.0922 mm
Terminal and Terminal Block Type PCB TERMINAL
Max Current Rating 2A
Contact Resistance 25mOhm
Contact Finish Gold
Orientation Straight
Pitch 1.27mm
HTS Code 8536.90.40.00
Number of Rows 1
Number of Positions 200
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2006
Packaging Tube
Operating Temperature -55°C~100°C
Physical
Mounting Hole Diameter 0.039 ~ 0.043 (0.99mm ~ 1.09mm)
Housing Material Brass
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 13 Weeks
