D01-9900505
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
ROHS3Compliant 2006 Gold Solder Pin Receptacle Connector -55C~100C 3.94muin 0.10mum
PDF
/
Inventory: 2529
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Beryllium Copper
Mounting Hole Diameter 0.039 ~ 0.043 (0.99mm ~ 1.09mm)
Technical
Operating Temperature -55°C~100°C
Packaging Tube
Published 2006
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 47
Number of Rows 1
HTS Code 8536.90.40.00
Pitch 1.27mm
Contact Finish Gold
Terminal and Terminal Block Type PCB TERMINAL
Hole Diameter 1.0922 mm
Flange Diameter 0.057 (1.45mm)
Tail Type No Tail
Accepts Pin Diameter 0.016 ~ 0.020 (0.41mm ~ 0.51mm)
Socket Depth 0.124 3.15mm
Pin Hole Diameter 0.043 (1.09mm)
Insertion Force 2.00N ~ 6.00N
Dimensions
Length 3.6068mm
Contact Finish Thickness 3.94μin 0.10μm
Length - Overall 0.142 3.61mm
Compliance
RoHS Status ROHS3 Compliant
