D01-9840301
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
IC & Component Sockets 3PC OF H3155-01 SKT ON CARRIER COMB
PDF
/
Inventory: 5894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Beryllium Copper
Contact Plating Gold, Tin
Mounting Hole Diameter 0.039 ~ 0.043 (0.99mm ~ 1.09mm)
Technical
Operating Temperature -55°C~100°C
Packaging Tube
Published 2006
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 29
Max Operating Temperature 100°C
Min Operating Temperature -55°C
Number of Rows 1
Pitch 1.27mm
Contact Finish Gold
Hole Diameter 1.0922 mm
Flange Diameter 0.057 (1.45mm)
Tail Type No Tail
Accepts Pin Diameter 0.016 ~ 0.020 (0.41mm ~ 0.51mm)
Socket Depth 0.124 3.15mm
Pin Hole Diameter 0.043 (1.09mm)
Insertion Force 2.00N ~ 6.00N
Dimensions
Length 3.6068mm
Contact Finish Thickness 3.94μin 0.10μm
Length - Overall 0.142 3.61mm
Compliance
RoHS Status ROHS3 Compliant
