D01-9790701
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - PC Pin Receptacles, Socket Connectors
Description
ROHS3Compliant 2013 Gold Solder Pin Receptacle Connector -55C~100C 3.94muin 0.10mum
PDF
/
Inventory: 6813
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Overall 0.297 7.54mm
Contact Finish Thickness 3.94μin 0.10μm
Length 7.5438mm
Technical
Insertion Force 2.00N ~ 6.00N
Tail Diameter 0.023 (0.59mm)
Pin Hole Diameter 0.043 (1.09mm)
Socket Depth 0.124 3.15mm
Accepts Pin Diameter 0.016 ~ 0.020 (0.41mm ~ 0.51mm)
Tail Type Standard Tail
Flange Diameter 0.057 (1.45mm)
Hole Diameter 1.0922 mm
Terminal and Terminal Block Type PCB TERMINAL
Contact Finish Gold
Pitch 1.27mm
HTS Code 8536.90.40.00
Number of Rows 1
Number of Positions 14
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2013
Packaging Tube
Operating Temperature -55°C~100°C
Physical
Mounting Hole Diameter 0.039 ~ 0.043 (0.99mm ~ 1.09mm)
Contact Plating Gold, Tin
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 13 Weeks
