85011-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Accessories
Description
Automotive Connectors RUBBER PLUG FOR SEALED CONN.
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.1936
≥100 USD $0.192896
≥500 USD $0.190432
≥1000 USD $0.176
≥3000 USD $0.144637
Inventory: 66412
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Radiation Hardening No
Dimensions
Length 9mm
Technical
Wire/Cable Diameter 3.8 mm
Contact Pattern RECTANGULAR
Contact Finish Termination GOLD
Dielectric Withstanding Voltage 500VAC V
Termination Type SOLDER
ELV Compliant
Body/Shell Style PLUG
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.224 inch
Operating Temperature (Min) -40°C
Contact Gender FEMALE
Body Breadth 0.1 inch
Operating Temperature (Max) 85°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 2.54mm
Orientation Straight
Total Number of Contacts 11
Contact Finish - Mating AU
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Black
Connector Type BOARD CONNECTOR
Part Status Active
Published 2005
Physical
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Type BOARD
Contact Material BRASS
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 15 Weeks
