TJHD22715
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Terminal Junction Systems
Description
TJHD RoHS Compliant 2008 MIL-T-81714 Connector Feedback Module Block 26AWG 200C 5A 21.5138mm
PDF
/
Inventory: 5316
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Plating Gold
Package / Case Module
Body Material Polyetherimide
Technical
Published 2008
Series TJHD
Size / Dimension 0.850Lx0.390W x 0.847 H 21.59mmx9.91mmx21.51mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Feedback Module Block
Max Operating Temperature 200°C
Min Operating Temperature -65°C
Current Rating 5A
Military Standard MIL-T-81714
Contact Gender Male
Insulation Resistance 5GOhm
Contact Size 22D
Wire/Cable Gauge 26 AWG
Module Capacity 21
Dimensions
Height 21.5138mm
Length 21.59mm
Width 9.906mm
Compliance
RoHS Status RoHS Compliant
