995199
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Wire to Board
Description
Omnimate LP M3 Non-RoHS Compliant Straight Wire Board Terminal Block 26AWG -20C~100C 15A 300V
PDF
/
Inventory: 7921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA66), Nylon 6/6
Contact Material - Plating Copper Alloy - Tin Plated
Technical
Operating Temperature -20°C~100°C
Packaging Bulk
Series Omnimate LP
Feature Interlocking (Side)
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
Color Black
Number of Rows 1
Pitch 0.200 5.08mm
Orientation Straight
Reach Compliance Code compliant
Number of Contacts 8
Wire Gauge 12-26 AWG
Voltage 300V
Number of Levels 1
Current 15A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 12 AWG
Number of Decks 1
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways 8
Safety Approval UL; VDE; CSA
Mating Orientation Horizontal with Board
Wire Termination Screw - Clamping Yoke, Tension Sleeve
Screw Thread M3
Compliance
RoHS Status Non-RoHS Compliant
